KIH Series High Frequency Induction Heating Machine
Keywords:
Description
Main Characteristics
1、Adopted European MOSFET,IGBT solid power module and advanced inverter technology.
2、Can set the time of three stages:“Heating”,”Maintain Temperature”,”Cooling”,separately.Furthermore,the function of adjusting the power of ”Maintain Temperature” independently will be effective to control the heating curve and the heating temperature.
3、Include “over-current, over voltage, water shortage, lack of phase and other fault state self-protected and display”,also some other necessary functions which will ensure our heater’s higher reliability and durability.
4、Easily operate and the output voltage is safe for operator.
5、Hundred Percent Rated Duty Cycle design,can work 24hours continuously.
Parameter
|
Type
|
KIH-5A
|
KIH-15A
|
KIH-15AB
|
KIH-25A
|
KIH-25AB
|
KIH-40AB
|
KIH-60AB
|
KIH-80AB
|
KIH-100AB
|
KIH-120AB
|
|
Max Fluctuating Power
|
5KVA
|
15KVA
|
15KVA
|
25KVA
|
25KVA
|
40KVA
|
60KVA
|
80KVA
|
100KVA
|
120KVA
|
|
Fluctuating Frequency
|
40-100KHZ
|
40-100KHZ
|
40-100KHZ
|
30-60KHZ
|
30-60KHZ
|
30-60KHZ
|
30-60KHZ
|
20-40KHZ
|
20-40KHZ
|
20-40KHZ
|
|
Heating Current
|
100-500A
|
200-600A
|
200-600A
|
200-800A
|
200-800A
|
200-1000A
|
200-1200A
|
300-1400A
|
300-1500A
|
400-1600A
|
|
Work Voltage
|
Single phase
220-240V 50HZ-60HZ |
Single phase
220-240V 50HZ-60HZ |
Single phase
220-240V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
3 Phases
380-420V 50HZ-60HZ |
|
The Range of Operating Voltage
|
190V-245V
|
190V-245V
|
190V-245V
|
342V-420V
|
342V-420V
|
342V-420V
|
342V-420V
|
342V-420V
|
342V-420V
|
342V-420V
|
|
The Flow Rate of Cooling Water
|
0.2Mpa
6L/Min |
0.2Mpa
6L/Min |
0.2Mpa
6L/Min |
0.2Mpa
6L/Min |
0.2Mpa
6L/Min |
0.2Mpa
8L/Min |
0.2Mpa
10L/Min |
0.3Mpa
12L/Min |
0.3Mpa
15L/Min |
0.4Mpa
20L/Min |
|
Water Temperature Protection Point
|
40℃
|
40℃
|
40℃
|
40℃
|
40℃
|
40℃
|
40℃
|
40℃
|
40℃
|
40℃
|
|
Net Weight(kg)
|
21kg
|
26kg
|
Main Part 25Kg
分机22Kg |
35kg
|
Main Part
32Kg Transformer Part 22Kg |
Main Part
40Kg Transformer Part 37Kg |
Main Part
57Kg Transformer Part 38Kg |
Main Part
72.5Kg Transformer Part 46.5Kg |
Main Part
85Kg Transformer Part 65Kg |
Main Part
105Kg Transformer Part 82Kg |
|
Dimension
(cmL×cmW×cmH) |
Integrated
180*330*410cm |
Integrated
460*200*385cm |
Main Part
460*200*385cm Transformer Part 315*200*350cm |
480*200*385cm
|
Main Part
480*240*400cm Transformer Part 315*200*350cm |
Main Part
556*280*470cm Transformer Part 360*265*365cm |
Main Part
800*470*560cm Transformer Part 500*304*402cm |
Main Part
500*304*402cm Transformer Part 800*470*560cm |
Main Part
500*304*402cm Transformer Part 800*470*560cm |
Main Part
800*470*560cm Transformer Part 850*470*560cm |
